ididit Cable Shift Linkage Kit: Chrysler Column to Chrysler 727&904 Transmission - Manual (Page 4)

8. The cable is the next piece that you are looking
for. Notice that both ends are the same. We did
that so that you could be right the first time. You
will need to take the small nut and the rubber
boots off so that you can get one large nut and
washer off. Put the cable through the column
bracket from the bottom side and reinstall the
large nut, washer and boots. Try to center the
nuts and washers on the available threads. This is important later.
9. Push the cable down through its outer cover so that it will be as short
as possible. Put the column in Park. Now, figure out where you
want the bracket to be, 5 o’clock will probably be a good place. Install
the swivel on the small thread and turn it until it is centered on the
thread. Now, install the small nut and turn it until
it bottoms out on the swivel. Do not tighten yet.
10. Rotate the bracket until the swivel drops into the
5/16” single hole 2” from the center of the main
shaft. If the bracket hits something or is in a bad
place, you can use another set of holes in the
horseshoe bracket, move the swivel up or down
its thread length, or move the cable on its length
of threads. Always remember that the cable that
moves must be pushed in all the way. Tighten the
bracket onto the tube.
11. Route the cable towards the front of the transmission. You may have
to bend it into a circle to take up the slack. Stay away from exhaust
pipes. If this cable gets too close, it will melt and not work.
3
