About the Scan Tool
ADJUSTMENTS AND SETTINGS
8 OBD2
E
■ The selected character displays “solid”, and the next character
begins flashing.
3. Select the remaining characters in the DTC in the same way, press-
ing the DTC SCROLL button to confirm each character. When
you have selected all the DTC characters, press the ENTER/LD
button to view the DTC definiition.
■ If you entered a “Generic” DTC
(DTCs that start with “P0”, “P2” and
some “P3”):
- The selected DTC and DTC defi-
nition (if available) show on the
Scan Tool’s display.
■ If you entered a “Manufacturer-
Specific” DTC (DTCs that start with
“P1” and some “P3”):
- The “Select Manufacturer” screen
displays.
- Use the UP and DOWN
buttons, as necessary, to high-
light the appropriate manufactur-
er, then press the ENTER/LD
button to display the correct
DTC for your vehicle.
If a definition for the DTC you
entered is not available, an advi-
sory message shows on the Scan
Tool’s display.
4. If you wish to view definitions for additional DTCs, press the
ENTER/LD button to return to the Enter DTC screen, and
repeat steps 2 and 3.
5. When all desired DTCs have been viewed, press the ERASE
button to exit the DTC Library.
Adjusting Display Brightness
1. Use the UP and DOWN but-
tons, as necessary, to highlight Adjust
Brightness in the MENU, then press
the ENTER/LD
button.
■ The Adjust Brightness screen dis-
plays.
