About the Code Reader
ADJUSTMENTS AND SETTINGS
CAN OBD2 7
E
ADJUSTMENTS AND SETTINGS
The CAN OBD2 Code Reader lets you make several adjustments and
settings to configure the Code Reader for your particular needs. The
following adjustments and settings can be made:
■ Adjust Brightness: Adjusts the brightness of the LCD display
screen.
■ Demo Mode: Sample data kept in the Code Reader’s memory to
use as examples and for demonstration purposes.
■ Select Language: Sets the display language for the Code Reader
to English/Spanish or English/French.
■ Unit of Measure: Sets the Unit of Measure for the Code Reader’s
display to USA or metric.
Adjustments and settings can be made only when the Code
Reader is NOT connected to a vehicle.
To enter the MENU Mode:
1. With the Code Reader “off”, press and
hold the UP button, then press and
release the POWER/LINK button.
■ The adjustments and setting MENU
displays.
2. Release the UP button.
DO NOT release the UP button until the adjustments and
settings MENU is visible on the display.
3. Make adjustments and settings as described in the following para-
graphs.
Adjusting Display Brightness
1. Use the UP and DOWN but-
tons, as necessary, to highlight Adjust
Brightness in the MENU, then press
the ENTER/FF
button.
■ The Adjust Brightness screen dis-
plays.
■ The Brightness field shows the cur-
rent brightness setting, from 0 to 43.
2. Press the UP button to decrease
the brightness of the LCD display (make
the display darker).
