Nissan/Infiniti
CODE RETRIEVAL PROCEDURE
27 Chapter 4
Nissan Code Retrieval Procedures (Cont)
Tool
Model Years Eng. Req? Perform the following:
Van 87-88, 2.4 Y Procedure: Access ECU (located under
90 passenger seat) (N5). Using Nissan tool,
Pathfin- 87-95 2.4, 3.0 turn diagnostic mode selector fully
der clockwise and observe LEDs on ECU.
Hard- 87-95 2.4, 3.0 When LEDs have blinked three times,
body turn selector fully counterclockwise.
Pickup Observe both red and green LEDs on
ECU for codes.
Codes: Codes are displayed by blinking
of both Red and Green LEDs (N10). The
Red LED blinks first, followed by the
Green LED. The Red LED indicates the
first digit (tens); the Green LED indi-
cates the second digit (ones). Example:
one Red flash and two Green flashes =
code 12 (N11).
240SX 89-90 2.4 Y Procedure: Access ECU (from passen-
ger side front kick panel) (N4), and posi-
tion it so LEDs can be observed. Using
Nissan tool, turn diagnostic mode selec-
tor fully clockwise and observe LEDs on
ECU. When LEDs have blinked three
times, turn selector fully counterclock-
wise. Observe both red and green LEDs
on ECU for codes.
Codes: Codes are displayed by blinking
of both Red and Green LEDs (N10). The
Red LED blinks first, followed by the
Green LED. The Red LED indicates
the first digit (tens); the Green LED in-
dicates the second digit (ones).
Example: one Red flash and two Green
flashes = code 12 (N11).
300ZX 86 3.0 (incl. Y Procedure: Access ECU (from passen-
Turbo) ger side front kick panel) (N4). Make
sure diagnostic mode selector is turned
fully counterclockwise. Turn ignition on.
Using Nissan tool, turn selector fully
clockwise. Observe both red and green
LEDs on ECU for codes.
Codes: Codes are displayed by blinking
of both Red and Green LEDs (N10). The
Red LED blinks first, followed by the
Green LED. The Red LED indicates the
first digit (tens); the Green LED indicates
