Honda/acura – Equus 3173 - Import Code Reader User Manual
Page 21
Honda/Acura
CODE RETRIEVAL PROCEDURE
Chapter 3
18
ECU/Test Connector Locations
The physical locations of the ECU or test connector for
Honda/Acura vehicles are shown in Figures H4 through H9.
Refer to the code retrieval instructions in Table H1 (Honda) or
Table H2 (Acura) to determine the correct location for your
vehicle.
H4
H5
H6
H7
H8
H9
