On Screen Display (OSD) Features
40 VTM-D15/A 15" MultiMedia Touch Panel Systems
Adjusting Horizontal and Vertical Screen Position
Horizontal (H Position) and vertical (V Position) settings allow you to adjust the position of the
picture. Press the button to optimize both the settings automatically. To customize the settings,
follow the steps below.
1. Press any one of the UP, DOWN, INCREASE or DECREASE buttons. The first OSD menu
appears.
2. Press the UP or DOWN button to highlight the Horizontal Position icon ( ), then press
INCREASE or DECREASE to center the picture horizontally.
3. Press the UP or DOWN button to highlight the Vertical Position icon ( ), then press
INCREASE or DECREASE to center the picture vertically.
4. Exit the OSD.
Selecting the Picture Color Temperature
You can change the picture color temperature of your display. Three preset color temperature
modes are available.
! 9300K: recommended for general use
! 6500K: recommended for color management
! 5500K: recommended for photo retouch
1. Press any one of the UP, DOWN, INCREASE or DECREASE buttons. The first OSD menu
appears.
2. Press the UP or DOWN button to highlight the Next Page icon ( ), then press INCREASE
or DECREASE. The second menu appears.
FIG. 27 Adjusting the Horizontal Screen Position
FIG. 28 Adjusting the Vertical Screen Position
