Configuration and Setup
27 VTM-D15/A 15" MultiMedia Touch Panel Systems
4. Type ?PAR again to verify the driver. The touch name should say Elo IntelliTouch.
Setting the Output Resolution
The output resolution for the monitor must be configured then calibrated.
To set the resolution:
1. Verify the connection of the output display monitor to the Monitor Out port at the rear of the
TPI/3.
2. Use the following command in Terminal Emulator mode:
Refer to the Specifications table on page 3 for the horizontal, vertical, and refresh rates available for
the output coming from the TPI/3.
Supported Touch Devices
Touch Device ID
No touch device 00
Microsoft serial mouse 01
2nd Microsoft Serial Mouse
(MX-MM Mobile Mouse
® )
02
Dynapro ® touch monitor 10
MicroTouch ® touch monitor 11
Elo IntelliTouch ® and VTM-D15/A
touch monitors
12
Elo AccuTouch ® touch monitor 13
EZ Screen
®
touch monitor 15
External touch driver FF
Mouse 12
This sets the TPI/3 touch device to the VTM-D15/A MultiMedia Touch Panel.
PRGM EX. 2
Available Resolutions
Resolution Refresh Rates
640 x 480 (VGA) 60 Hz, 72 Hz, 75 Hz, 85 Hz
800 x 600 (SVGA) 56, Hz, 60 Hz, 72 Hz, 75 Hz
1024 x 768 (XGA) (default) 60 Hz
Resolution x:
Allows you to set the resolution (horizontal/vertical) and refresh rate of the touch panel.
PRGM EX. 3
Resolution 1024x768:60
This sets the TPI/3 to send a video signal at 1024 x 768 with a refresh rate of 60 Hz.
PRGM EX. 4
If the video is blurry, try a different refresh rate and/or resolution. Check the output
device to verify you are using refresh rates and resolution settings are compatible
with the device.
