PARTS LIST - HYDRAULIC PLUMBING - MODEL I-155TS
Key No. Part No. Description
1 A155H01 Tubing, Front, Top, Far Right and Far Left
2 A155H02 Tubing, Front, Top, 2nd From Right
3 A155H03 Tubing, Front, Top, 2nd From Left
4 A155H04 Tubing, Front, Bottom, Outside
5 A155H05 Tubing, Front, Bottom, Inside
6 A155H06 Tubing, Top, Right Side
7 A155H07 Tubing, Top, Right Side
8 A155H08 Tubing, Top, Right Arm
9 A155H09 Tubing, Bottom, Outer, Right Arm
10 A155H10 Tubing, Bottom, Inner, Right Arm
11 A155H11 Tubing, Top, Left Side
12 A155H12 Tubing, Top, Left Side
13 A155H13 Tubing, Top, Left Arm
14 A155H14 Tubing, Bottom, Outer, Left Arm
15 A155H15 Tubing, Bottom, Inner, Left Arm
16 A155H16 Tubing, Back, Outer Right
17 A155H17 Tubing, Back, Inner Left
18 A155H18 Tubing, Back, Outer Left
19 A155H19 Tubing, Back, Inner Right
20 A155H20 Tubing, Wraps Around Back of Bowl
21 A155H21 Tubing, Short, Left Side of Bowl
22 A155H22 Tubing, Top, Around Left Side of Bowl
23 A155H23 Tubing, Bottom, Around Left Side of Bowl
24 A155H24 Tubing, Around Right Side of Bowl
25 AHA-00009 ADAPTER: 90 DEG. 3/4 M JIC X 1/2 F NPT
26 AHA-00019 ADAPTER: 90 DEG. 3/4 M JIC X 3/4 M JIC
27 AHA-00022 ADAPTER: T 3/4 M JIC X 3/4 M JIC X 3/4 M JIC
28 AHA-00015 ADAPTER: T 3/4 M JIC X 3/4 F NPT X 3/4 M JIC
29 AHA-00018 ADAPTER: 90 DEG. 3/4 M JIC X 3/4 M NPT
30 AHL-00004 CLAMP, HYD TUBING: 4 TUBE
31 AHL-00001 CLAMP, HYD TUBING: 1 TUBE
32 AHL-00022 CLAMP, HYD TUBING: 2 TUBE STACKING
33 AHL-00022 (2) CLAMP, HYD TUBING: 3 TUBE STACKING
34 AHL-00002 CLAMP, HYD TUBING: 2 TUBE
35 A45H07 ADAPTER: 90 DEG. SWIVEL 3/8 M NPT X 1/2 F NPT
36 AHA-00020 ADAPTER: T 3/4 F NPT X 3/4 F NPT X 3/4 F NPT
37 AHA-00006 ADAPTER: STR. 3/4 M JIC X 3/4 M NPT
38 A22H03 ADAPTER: 90 DEG. SWIVEL 3/8 M NPT X 3/8 F NPT
39 A175H17 ADAPTER: T 3/4 M JIC X 3/4 M NPT X 3/4 M JIC
40 AHA-00014 ADAPTER: T 1/2 F NPT X 1/2 F NPT X 1/2 F NPT
41 AHA-00005 ADAPTER: STR. 3/4 M JIC X 1/2 M NPT
42 AHA-00010 ADAPTER: 90 DEG. 3/4 M NPT X 3/4 F NPT
43 AHA-00021 ADAPTER: 45 DEG. 3/4 F NPT X 3/4 M NPT
44 AHA-00017 ADAPTER: HEX REDUCER BUSHING 3/4 M NPT X 1/2 F NPT
45 AHA-00030 ADAPTER: 90 DEG. 3/4 M JIC X 3/4 M NPT EXTRA LONG
46 AHF-00025 DUST CAPS
47 AHF-00023 FEMALE QUICK COUPLERS
48 AHA-00026 ADAPTER: 90 DEG. 1-1/16 MORB X 3/4 F NPT
49 AHA-00037 ADAPTER: STR. SWIVEL 1-1/16 MORB X 3/4 F NPT
50 A101H77 ADAPTER: 90 DEG. SWIVEL 3/4 M NPT X 3/4 F NPT
51 AHL-00004 CLAMP, HYD TUBING: 4 TUBE
52 A155H25 Tubing, Around Left Side of Bowl
53 A101H48 Counterbalance Valve
54 A101H47 Sequencing Valve
55 AHA-00025 ADAPTER: HEX REDUCER BUSHING 1/2 M NPT X 3/8 F NPT
