Ashland I-155-TS2 User Manual
Page 26
KEY NO.
PART NO.
DESCRIPTION
1.
A140H20
Barrel Assembly: 5” Bore
2.
A400H06
O-Ring: 5” OD X 4-1/2” ID
3.
A400H05
Back Up Washer: 5” OD X 4-1/2” ID
4.
A140H21
Head Gland: 5”
5.
AFB-00061
Set Screw: 3/8” NC
6.
A140H19
Collar
7.
A140H07
Shaft Seal: 2-1/2” ID X 3” OD OU-Cup
8.
A140H08
Wiper Seal: 2-1/2” ID X 2-15/16” OD
9.
8602
Cotter Pin: 1/4” X 2”
10.
A14033
Pin: 1-1/4” Dia. X 5” Lg.
11.
A140H27
Shaft: 2-1/2” Dia.
12.
A175H06
Spacer
13.
A22H15
O-Ring: 1-1/2” x 1-3/4” OD
14.
A140H22
Piston: 5”
15.
A140H24
Piston Seal: 5” OD X 4-1/4” ID
16.
A140H25
Wear Ring: 5” OD
17.
AFN-00018
Lock Nut: 1-1/2” NF
18.
A9024
Pin: 1-1/4” x 4-3/4”
A140H28
Packing Kit: Containing:
(1) A140H25
(1) A400H06
(1) A140H07
(1) A140H08
(1) A22H15
(1) A400H05
(1) A140H24
MODEL I-155 TS
PUSHOFF CYLINDER 5 X 60”
PART NO. A560H114A
