29

IP Message Actions

Address indicates the network IP address and port of the target device. This may be up
to 24 characters long and must consist of an IP address in dotted-quad format, followed
by a colon, followed by a port number in the range of 0 to 32767. The default setting of
“0.0.0.0

:23

” indicates no action to be taken.

Message – Alarm holds a text message of up to 31 characters. When the local alarm is
triggered this message will be sent to the entered IP address.

Message – Clear holds a text message of up to 31 characters. When the local alarm is
cleared this message will be sent to the entered IP address.

Repeat – This checkbox enables a function which will cause the N-TAH to send the
current status of this alarm to the entered IP address repeatedly.

Repeat time – this holds a numerical value from 0 to 9999 which gives the interval in
seconds at which the status of the alarm will be sent to the entered IP address if the
Repeat checkbox is enabled.

Setting

Default Value

Range

IP:PORT

“0.0.0.0:23”

24 characters

Message – Alarm

31 characters

Message – Clear

31 characters

Repeat

Off

On or off

Repeat time

15 seconds

0-9999 seconds
