MN078-1 Rev F
8/12
25
[Read the Important Safety Rules section before operating this equipment.]
2. Locate the air outlet barb fitting on the front of the unit (Figure 2). If a hand held nebulizer will be used, connect one end of
the air supply tubing to the air outlet barb fitting and the other end to the bottom of the nebulizer.
3. Fill the nebulizer cup with medication as prescribed by your physician
(Refer to the Nebulizer With Medication section for filling instructions).
4. Operate the NewLife Elite unit for at least five minutes, and then
open the air valve completely (Figure 3).
5. Begin your treatment (Refer to the Inhaling Medication/Treatment Instruction sections).
Nebulizer medication will now be visible as a fine mist.* Figure 3
Oxygen-enriched air is not delivered at the air outlet.
In high humidity environments or during extended period of non-use, open the air
valve completely (Figure 3) to purge/flush the system.
