9 Document # 2102196 RevA
UP
DOWN
LOW BATTERY
UP
DOWN
LOW BATTERY
Figure 6. Moving the
LiftMate into position
Figure 5.
Figure 8. Figure 7. Raising the
patient on the LiftMate
OPERATION (Continued)
Patient Handling with the LiftMate
(Positioning the LiftMate and raising the patient)
1. Extend casters. Figure 5.
2. Position the back of LiftMate against foot end or side of
exam table. Figure 6.
3. When in position allow casters to retract by releasing the
button.
4. Assist patient by having them walk forward onto LiftMate
platform.
5. Once patient is on LiftMate assist them in turning around so
their back is toward exam table, and they are grasping the
platform handrail. Figure 7.
6. Press “UP” on the hand pendant to raise patient to the
height that is best for seating them. Figure 8.
7. Seat patient onto exam table.
8. Platform may be left in the “UP” position. To lower platform
press “DOWN” on the hand pendant, Figure 9 next page.
9. Note: LiftMate may be left in position at the foot end of
exam table, or moved out of the way depending upon pro-
cedure or preference of clinician.
UP
DOWN
LOW BATTERY
Figure 4. Caster Extend/Retract Button
Moving the LiftMate
The LiftMate moves about easily on four extendable/re-
tractable casters.
To extend casters depress the “PUSH AND HOLD TO
MOVE” button on the hand pendant. See Figure 4. Cast-
ers will extend allowing the LiftMate to be moved to the
desired location. The button must be held to keep casters
extended. Releasing the “PUSH AND HOLD TO MOVE”
button will cause casters to retract, lowering the LiftMate
onto the four base feet providing a stable unit for the
patient to step onto.
CAUTION
● Do not lower LiftMate onto wet, or slippery surfaces,
or onto objects that may cause imbalance
● Make sure operator and patients feet are clear of
unit before lowering.
● Make sure path of travel is free of obstructions that
may cause unit to tip.
