4 Document # 2102196 RevA
SPECIFICATIONS
Power Cord..................................... Extends 10 ft. from unit.
18 AWG / 3 conductor, SJT grey jacketed with hospital plug
Type of protection against electrical shock
Class ............................................ Class II Double Insulated
Type of protection against electrical shock .........................
B Applied Parts
Certifications*
UL60601-1; IEC60601-1; CAN-CSA C22.2 No. 601.1
Battery Specifications
Type ............................................Sealed Lead Acid Storage
Charging .........Battery is charged through Control Box only
Temperature (Ambient Operating) ................. 41°F to 104°F
Output ............................................................ 24 V DC, 10A
Duty Cycle .... 2 minutes on/18 minutes off (motor run time)
Operating Conditions
Temperature Range.........................................65°F to 85°F
Relative Humidity...............................................10% to 90%
Transportation and Storage
Temperature Range .......................................-20°F to 150°F
Humidity.............................................................10% to 90%
Weight of LiftMate .................................................. 105 lbs.
Load Rating (maximum):
- Platform ............................................................... 500 lbs.
- Platform Range .......................................... 1.0 to 10.0 in.
LiftMate Dimensions:
Platform Width (Inside) ........................................ 21 3/8 in.
Platform Depth (Inside)........................................ 18 1/4 in.
Distance Between Inner Shrouds ........................ 24 1/4 in.
Distance Between Platform Handrails (Inner Surfaces) 28 in.
Width Between Outer Shrouds ............................ 34 3/4 in.
Base Width (Outer) .............................................. 31 3/4 in.
Base Depth (Outer) ............................................. 21 1/2 in.
Mat Dimensions
Width .................................................................. 19 1/2 in.
Width ......................................................................... 17 in.
Caster Dimensions
Diameter ...................................................................... 2 in.
Width ........................................................................... 2 in.
Electrical Specifications
115 VAC nominal, 60 HZ, 4 amps max.
Failure to follow instructions with this symbol
could result in serious personal injury and/or damage
to the unit.
DANGER
indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING
indicates a potentially hazardous
situation which, if not avoided, could result in death
or serious injury.
CAUTION
indicates an imminently or poten-
tially hazardous situation which, if not avoided, may
result in serious injury and/or equipment damage.
SAFETY INFORMATION
Safety Information
The primary concern of The Brewer Company is that the
equipment is operated and maintained with the safety of
the patient and healthcare staff in mind. To ensure safe
and reliable operation:
● Read and understand all instructions in this manual
before attempting to install or operate the unit.
● Ensure that appropriate personnel are informed on
the manual contents. This is the responsibility of the
purchaser.
● Ensure that this manual is located near the LiftMate,
or if possible permanently affixed to the unit.
