14 Document # 2102196 RevA
SERVICE PARTS
Kit Name Order Kit # Description
Rubber Feet 2102273 Set of (4) replacement feet for legs.
Casters 2102275 Set of (4) replacement casters .
Short Caster Actuator 2102277 One short caster actuator for right rear or left front casters.
Long Caster Actuator 2102279 One long caster actuator for left rear or right front casters.
Lift Actuator 2102281 Set of (2) lift actuators.
Power Cord 2102283 Replacement power cord that plugs into wall receptacle.
Power Cord Hooks 2102285 Set of (2) Hooks on right side of LiftMate that secure the power cord.
E-Stop Interface Button 2102287 Red Button that attaches to the outside shroud. The emergency stop
switch is inside the unit and is connected to the other side of this button. Kit
includes (1) button.
E-Stop Switch 2102289 The switch that is mated to the E-Stop button. The kit includes (1) switch.
The switch disconnects power to the lift actuators only.
Hand Pendant 2102291 Replacement hand pendant with strain relief and button graphics label
attached.
Hand Pendant Hook 2102293 Hook for hanging hand pendant when not in use.
Back Cover 2102295 Sliding two piece cover that spans the gap between the platform and base.
Platform Mat 2102297 Slip resistant mat that covers the top of the platform.
Platform Bumper 2102299 Yellow rubber strip covering the front edge of the platform.
Right Outer Shroud 2102301 Right outside cover with power cord hooks and E-Stop button attached.
Left Outer Shroud 2102303 Left outside cover with E-Stop button attached.
Right Inner Shroud 2102305 Right inside cover.
Left Inner Shroud 2102307 Left inside cover.
Battery 2102309 Replaceable storage battery specifically designed for this unit.
Control Box 2102311 Control unit through which the power cord is connected and the battery is
charged. The hand pendant input and the lift and caster actuator outputs are
connected as well. Lift actuator synchronization and battery management is
monitored through the control box.
E-Stop Wiring Harness 2102313 The wiring harness that connects to the E-Stop switches and allows power to
operate the lift actuators when switches are in their normal state.
L Caster Actuator Harness 2102315 The wiring harness that brings power to the left caster actuators.
R Caster Actuator Harness 2102317 The wiring harness that brings power to the right caster actuators.
L Lift Actuator Harness 2102319 The wiring harness that brings power to the left lift actuator.
R Lift Actuator Harness 2102321 The wiring harness that brings power to the right lift actuator.
Battery Wiring Harness 2102323 The wiring harness that goes from the control box to a receptacle that the
battery plugs into. Charge current to the battery and power from the battery
travel through this harness.
All kits include applicable hardware and step-by-step instructions.
