64 Chapter 3
Screw List
Item Description
A SCREW M2.5X0.45+4A-BNI
B SAFETY SCREW M2.5X0.45+6FP-ZK(NL)
C SCREW M2.5X0.45+10FP-ZK(NL)
D SCREW M2.5X0.45+16FP-ZK (NL)
E SCREW M2.0X4FP-ZK(H3.5-3.8XT0.6)
F SCREW M2.5X0.45P+3K-ZK(NL)
G SCREW M2.0X0.4P+2.3FP-ZK
H SCREW M3.0X0.8+3K-NL
I THERMAL SCREW (Front)
J SCREW M2.0X0.4P+3FP-NI
Main Unit
Bx1
Dx9
Cx5
Lower Case
Mini PCI
Wireless Card
Thermal
Module
Ix2
Ox2
CPU
Main Board
Assembly
Upper Case
Assembly
Ax2
Bx4
I/O Bracket
Main Frame Main Board
Ax2
MDC Cable MDC Card
Fx3
Support
Bracket
Fx2
Upper Case
Shielding
Ax2
Touchpad
Button Board
CD-Player
Button
Assembly
Fx5
FFC (Touchpad
Button to
Touchpad)
Touchpad
Touchpad
Cover
Upper
Case
Antenna
Line
CD-Player
Support
CD-Player
Button
FFC (CD-
Player Board
to Touchpad
Button Board)
CD-Player
Board
Bx2
Jx2
