30 Chapter 1
Electrical Characteristics
No
.
Parameter Symbol Min. Typ. Max. Unit Comment
1 Input
voltage NV_PWR 9 14.8 21 V 7.5V (continuous) can
work
*Note 1
2 Input
current Iin -- 0.33 -- A
3
Lamp
current IL 3.0 -- 6.8 mA DAC=0V
*Note 2
4
Lamp
current IL 2.7 -- 6.3 mA DAC=1V
4
Frequency
F 45
55
65
KHz
* Note 3
5 Output
power Pout -- -- 4.5 W
6 Efficiency η 80% -- -- --
7 Starting
voltage Vs 1600 -- --- V At 0’C
8 Starting
time Tvs 1 -- 1.5 Sec
9 Dispoff# 2.8 3.3 3.6 V Backlight on/off signal
0 0.5 0.8 V Low level
10 Limited
lamp
maximum
current DAC-
BRIG 0 3.3 V *Note 2
11 PWM
signal
*Note 4 INV_PW
M 142 150 158 Hz PWM signal frequency
3.0 3.3 3.6 V PWM signal amplitude
30 -- 100 %
12 Lamp
current
over-shoot I zero-PK -- -- 10 % Line transient (10.8V to
21V/100us) and turn on
transient
13 Current
Waveform
factor 1.27 1.56 Multiple
or *10
14 Unbalance
Rate -10% 0 +10% Mulitple
15 Turn off
current
(Hight
side) IHl -- -- 0 A PWM=30%
15 Turn off
voltage
(Low side) Voff -- -- 150Vp-
p V PWM=30%
Duty
Ton
Period
------------------- =
rms
p
I
I
2
rms
p
I
I
−
rms
p p
I
I I
−
−
