5-45
Servicing
Replaceable Parts
Table 5-10. Top and Bottom View Parts
Item
Agilent Part
Number
Qty Description
1 0515-1400 6 Screw, TORX T10 90
°
Flat Head, M3.5 x 0.6, 8mm long
2 5041-8803 1 Trim strip, top (not shown)
3 1252-7513 8 Ribbon cable clip
4 83437-00004 1 A2MP2, Sheet-metal optical deck (part of A2 assembly)
5 83437-00008 1 Sheet-metal power supply deck
6 86120-00011 1 Shield for A4 Power Supply
7 1400-0755 2 Component clip 0.75 in x 0.75 in
8 1400-0249 1 Cable tie wrap
9 — 1 A2MP1, LED heat sink (part of A2 assembly)
10 — 1 Fiber container lid (part of A2 assembly, not separately orderable)
11 — 1 Fiber container (part of A2 assembly, not separately orderable)
12 — 1 Fiber track (part of A2 assembly, not separately orderable)
13 0515-0830 2 Screw, TORX T10 Pan Head, M3 x 0.5, 28 mm long
14 0515-0380 4 Screw, TORX T15 Pan Head, M4 x 0.7,10 mm long
15 0515-0372 14 Screw, TORX T10 Pan Head, M3 x 0.5, 8 mm long
16 — 8 Screw (part of A2 assembly, not separately orderable)
