Page 81
5-27
Servicing
Replacing Instrument Assemblies
To remove the instrument cover
1
Disconnect the power cord from the instrument.
2
Position the instrument so that you are looking at the rear panel.
3
Use a T-15 TORX driver to back out the screw that attaches the top cover to
the instrument.
Note that the screw is permanently secured to the cover.
4
After the screw is backed out, slide the cover toward the rear of the instrument
to remove it.
5
Remove the bottom cover using the same technique as used for the top cover.
6
Remove the two side covers.
