5-29
Servicing
Replacing Instrument Assemblies
6
Be sure to cover the exposed end of the fiber-optic cable.
7
Use a T-10 TORX driver to remove the four screws securing the A2 assembly
to the instrument’s right-side frame.
8
Place the instrument on it’s right side.
9
Use a T-10 TORX driver to remove the three screws securing the A2 assembly
to the bottom of the instrument’s main deck sheet metal assembly.
10
Remove the A2 assembly.
