5-39
Servicing
Replaceable Parts
Table 5-7. Cable Assemblies
Reference
Designator
Agilent Part
Number
Description
W1
—
Input fiber optic cable (Part of A2 assembly)
W2
83437-60008
Line switch cable (includes FL1 and LINE switch), to A4J1
W3
—
A3J7 to B1 (Part of B1)
W4
83437-60003
Power supply cable, A2A2J2 pin 5 to front-panel “LINE” LED indicator (green wire)
W5
83437-60004
Power supply cable, A2A2J1 to front-panel “ACTIVE” LED and A1 assembly
W6
83437-60001
Power distribution cable, A4J2 to A3J6
W7
83437-60002
Modulation cable, A3J5 to A2A2J2
W8
83437-60013
Driver cable, 11 inches long, A3J1 to A5J2
W9 - W11
—
Not assigned
W12
83437-60020
Ribbon cable, A2A2J91 to A5J1
W13 - W16
—
Not assigned
W17
8120-5056
SMB to BNC cable, 55.5 cm, rear-panel J1 to A2A2J21
—
1252-7513
Ribbon cable clip for W12, W13, W14, and W15.
