Printhead Cleaner Removal
When removing the printhead cleaners:
Be careful not to get ink on your hands. There
may be ink on, around and inside the replaced
printhead cleaner.
Do not lay the replaced printhead cleaner on its
side or turn it upside down, as ink may leak out.
Always handle and store the replaced printhead
cleaner upright to avoid spilling any ink.
CAUTION When replacing a printhead always
replace the corresponding printhead
cleaner. Leaving the old printhead
cleaner in the printer will seriously
shorten the new printhead’s life and
possibly damage the printer.
Click on this icon to run the animation sequence.
A printable version of the sequence is also available so that you can take the key illustrations
to the printer, if it is remote from your computer.
