For instructions on how to use the take-up reel see Use the take-up reel on page 26 .
Load a roll into the printer (manually)
The manual loading process should be used if the media you are using is thinner of thicker than normal.
In addition this process can also be used if the media has excessive curl or the printing side of the media
faces outwards. If the media you are using is a standard type of media and in good condition, use the
automatic load process described previously, see
Load a roll into the printer (automatically)
on page 19
To start this procedure, you need to have a roll loaded on the spindle. See Load a roll onto the
spindle on page 16 .
The normal minimum substrate width is 23 inches (584 mm). To load substrates down to a minimum
width of 10 inches (254 mm), go to the front panel and select the icon, then select Substrate handling
options > Enable narrow substrate. With this option, print quality is not guaranteed. To load a roll of
textile material see
Loading textile types of media on page 36
1. At the printer's front panel, select the icon, and then select Substrate load > Manual load.
2. Lift the substrate-adjustment lever as far up as it will go.
22 Chapter 4 Handle the substrate ENWW
