Component identification 15

The hard drive activity LED will not illuminate if using SATA drives connected to the embedded storage

device. In this configuration, SATA hard drive activity can be identified using the LED on the system front

panel.

Fan locations

NOTE: The air baffle and the processor heatsink are removed for clarity.

Item

Description

1 System

fan

2

Hard drive cage fan
