Component identification 13
Item LED description Status
11 Single bit error Amber = Single bit error limit has been
exceeded
Off = Normal
12 System fan failure Amber = System fan has failed
Off = Normal
System LEDs and internal health LED combinations
When the internal health LED on the front panel illuminates either amber or red, the server is experiencing
a health event. Combinations of illuminated system LEDs and the internal health LED indicate system
status.
NOTE: The system management driver must be installed for the internal system health LED to provide pre-
failure and warranty conditions.
The front panel health LEDs indicate only the current hardware status. In some situations, HP SIM (" HP
Insight Diagnostics " on page 46 ) may report server status differently than the health LEDs because the
software tracks more system attributes.
System LED and color Internal health LED
color
Status
Processor failure,
socket X (Amber)
Red One or more of the following conditions may exist:
• Processor in socket X has failed.
• Processor X is not installed in the socket.
• ROM detected a failed processor during POST.
Amber Processor in socket X is in a pre-failure condition.
PPM failure, slot X
(Amber)
Red • PPM in slot X has failed.
• PPM is not installed in slot X, but the corresponding
processor is installed.
DIMM failure, slot X
(Amber)
Red • DIMM in slot X has failed.
• DIMM has experienced a multi-bit error.
Amber • DIMM in slot X has reached single-bit correctable
error threshold.
• DIMM in slot X is in a pre-failure condition.
DIMM bank error (all
slots in one bank,
Amber)
Red The bank is not populated entirely or DIMMs do not all
match within the bank.
DIMM failure (all
slots, Amber)
Red • No valid or usable memory is installed in the system.
• The banks are not populated in the correct order.
System temperature
alert (Amber)
Red System temperature has exceeded OS cautionary level or
critical hardware level.
Fan (Amber) Red A required fan has failed.
