HA-Fabric Manager user guide 127
• Remove a zone from a zone set (see ” Removing a zone from a zone set ” on page 130).
• Activate a zone set (see ” Activating a zone set ” on page 130).
• Deactivate a zone set (see ” Deactivating a zone set ” on page 131).
• Enable or disable the default zone (see ” Enabling and disabling the default zone ” on
page 132).
• Export a zone set (see ” Exporting a zone set ” on page 133).
• Import a zone set (see ” Importing a zone set ” on page 134).
NOTE: Only one appliance should perform discovery at a time; otherwise logon conflicts may
occur.
Displaying the zone library
To display the zone library:
1. Select Configure > Zoning from the HAFM menu bar.
The Zoning dialog box appears. (
Figure 78 ).
Figure 78 Zoning dialog box
2. Select a fabric from the Fabric list.
This defines the fabric for the zoning actions.
3. Click the Zone Library tab.
