HP XP Array Manager Software - Manual (Page 61)

Return Codes, Output Messages, and Error Codes 5-7
Hitachi Cache Manager User’s Guide
Error
Number
Error Message Recommended Action
JSE231I-S ALREADY BOUND TO
CACHE BY [BIND or
PRIO] MODE The command to reside data using PRIO mode was made to the BIND mode area, or vice
versa.
(S) HRUDCRX terminates abnormally. (Return code is 12.)
(P) Check the mode of the already resident area and correct the parameter, then execute
the command again.
JSE232I-S EXTENT OVER ON
BOUND TO CACHE The number of resident extents exceeds the limitation. Maximum number of extents is:
ƒ For USP V, 4096 per volume or 16384 per storage system.
ƒ For USP/NSC, 4096 per volume or 4096 per storage system.
ƒ For 9900V/9900, 1024 per volume or 1024 per storage system.
(S) HRUDCRX terminates abnormally. (Return code is 12.)
(P) Check the remaining number of available resident extents. If the number is too small,
release the unnecessary resident extents, then execute the command again.
JSE233I-S EXTENT MODE LIMIT IS
DUPLICATED The area specified by the DSMODE/ENABLE command has already been enabled.
(S) HRUDCRX terminates abnormally. (Return code is 12.)
(P) Disable the area using the DSMODE/ECCENTRIC operand, then reissue the command.
JSE234I-S EXTENT MODE LIMIT IS
A PART OF DATASET
EXTENT The area specified by the DSMODE/DISABLE command has already been enabled.
(S) HRUDCRX terminates abnormally. (Return code is 12.)
(P) Disable the area using the DSMODE/ECCENTRIC operand, then reissue the command.
JSE235I-S EXTENT MODE OVER ON
BOUND TO CACHE
SUBSYSTEM The number of dataset statistics extents exceeds the maximum, which is 64 per storage
system.
(S) HRUDCRX terminates abnormally. (Return code is 12.)
(P) Check the remaining dataset extents. If the number is too small, release any
unnecessary area. Then execute the command again.
JSE2361-S UNABLE TO EXECUTE
FOR DKC The command was executed on a storage system that does not have Cache Residency
Manager installed.
(S) HRUDCRX terminates abnormally. (Return code is ‘8’.)
(P) Install Cache Residency Manager in DKC and then execute the command again.
JSE2371-E CLPR FUNCTION UNABLE
TO EXECUTE FOR DKC
KIND=xx The command cannot be executed because the Cache Logical Partition (CLPR) function is
not installed in the DKC.
DKC KIND: 05 for USP V, 04 for USP/NSC, 03 for 9900V, 02 for 9900
(S) HRUDCRX terminates abnormally. (Return code is ‘8’.)
(P) Install the Cache Logical Partition (CLPR) program product in DKC and then execute the
command again
JSE2381-E CLPR FUNCTION IS
INVALID The specified volume does not belong to the Cache logical Partition (CLPR).
(S) HRUDCRX terminates abnormally. (Return code is ‘8’.)
(P) Check the definition of Cache Logical Partition (CLPR) information and then execute the
command again.
JSE2391-E CATALOG ACCESS
ERROR（return code,
reason code, module ID
）
{CATALOG ‘catalog
name’ DATASET ‘dataset
name’}
The error occurred on accessing to catalog.
(S) HRUDCRX terminates abnormally. (Return code is ‘8’.)
(P) Check the specified dataset name or catalog name and then execute the command
again.
