NOTE:
•
The Default value for CIMOM Port is 5988.
•
The Default value for Read Community is public.
While installing HP CIMServer on the remote host, and if the user has used a non default
port then, enter the same here.
3. Click Start Discovery to start the discovery process.
•
Based on the discovery-protocol-specific authentication process, all connected switches
are discovered and follow the step specified in 1a.
•
Based on the discovery-protocol-specific authentication process, it discovers all the
switches within the IP address range and follow the step specified in 1b.
4. The discovered switches are displayed with the following details: IP Address, Switch
Name, Vendor, Model, State, Edit, and Status as shown in
Figure 7 (page 18) .
Figure 7 Discovered Switches
For information on switch states, see “Switch Details” (page 19) .
5. Select the check box of the discovered switch(es) to perform one of these actions:
•
Click on Monitor switch(es) to perform the data collection, monitoring, and SFP
diagnostics.
•
Delete – removes the components from the profile.
•
Test connectivity – tests the network connectivity of the components.
6. Click Next, to select the Hosts to be monitored.
The following message is displayed if no switches are selected for monitoring:
18 Using HP IIAS
