Cabling 56

Four-bay LFF hot-plug drive cage cabling

•

Mini-SAS cable connected to the system board

Item

Description

1

Power cable

2

560-mm Mini-SAS cable

•

Mini-SAS cable connected to a storage controller in the full-height expansion slot

Item

Description

1

Power cable

2

Capacitor pack cable

3

890-mm Mini-SAS cable
