Alliance Laundry Systems CHM1772C - Manual (Page 8)

© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8321401 (EN) 6
Basic Installation/Operation
Specifications and Dimensions
2 Speed Models
Specification 20 30 40 60
Weight and Shipping Information
Net weight, lbs. (kg) 387
(176)
489
(222)
692
(314)
812
(368)
Domestic shipping weight, lbs. (kg) 420
(191)
530
(240)
734
(333)
854
(387)
Domestic shipping volume, ft
3
(m
3
) 30.5
(0.86)
40.75
(1.15)
50
(1.42)
64
(1.81)
Export shipping weight lbs., (kg) 475
(215)
593
(269)
816
(370)
948
(430)
Export shipping volume, ft
3
(m
3
) 36.2
(1.03)
49.9
(1.41)
60
(1.70)
75.8
(2.15)
Wash Cylinder Information
Cylinder diameter,
in. (mm) 21
(533)
24
(610)
26.25
(667)
30
(762)
Cylinder depth, in. (mm) 13.75
(349)
16
(406)
20.25
(514)
22
(559)
Cylinder volume, ft
3
(l) 2.76
(78.1)
4.19
(118.6)
6.34
(180)
9.00
(255)
Perforation size, in. (mm) 0.188
(4.76)
0.188
(4.76)
0.188
(4.76)
0.188
(4.76)
Perforation open area, % 17 23 17.5 18
Door Opening Information
Door opening diameter, in. (mm) 11.63
(295) 14.34
(364)
16.25
(413)
16.25
(413)
Height of door bottom above floor, in. (mm) 14.38
(365)
14
(356)
14.5
(368)
15
(381)
Height of door opening above floor, in. (mm) 17.19
(437)
17
(431)
19
(483)
18.5
(470)
Power Consumption
Average power used per cycle,
kW-hr No load 0.06 0.13 0.196 0.25
Sheets 0.10 0.14 0.195 0.26
Towels 0.11 0.16 0.213 0.33
Average HVAC load, Btu/hr. (Kcal./Hr.) 425
(107)
463
(117)
510
(129)
700
(176)
Table 1 (Continued)
