Basic Installation/Operation
9
F8321401 (EN)
Table 2
Table 2 (Continued)
Variable-Speed and Fixed-Speed Models (Continued)
Specification
20
30
40
60
80
125
Cylinder Speeds
Gentle wash/reverse speed, RPM
29
27
26
26
22
26
Wash/reverse speed, RPM
52
52
46
43
40
37
Distribution speed, RPM
92
92
82
77
70
65
Low extract speed, RPM
366
366
328
307
280
260
Medium extract speed, RPM
(Not available on Electronic Control models.)
534
534
478
447
408
378
High extract speed, RPM
686
686
613
574
524
485
Centrifugal Force Data
Gentle wash centrifugal force, Gs
0.25
0.25
0.25
0.25
0.25
0.43
Wash/reverse centrifugal force, Gs
0.8
0.8
0.8
0.8
0.8
0.8
Distribution centrifugal force, Gs
2.5
2.5
2.5
2.5
2.5
2.6
Low extract centrifugal force, Gs
40
40
40
40
40
40
Medium extract centrifugal force, Gs
85
85
85
85
85
85
High extract centrifugal force, Gs
140
140
140
140
140
140
Direct Steam Heating (Optional)
Steam inlet connection size,
in. (mm)
N/A
N/A
1/2
(13)
1/2
(13)
1/2
(13)
3/4
(19)
Number of steam inlets
N/A
N/A
1
1
1
1
Steam required to raise bath water
temperature 10°F (6°C), lbs. (kg)
LOW
N/A
N/A
2.09
(0.94)
3.6
(1.63)
2.58
(1.17)
3.64
(1.65)
MED
N/A
N/A
2.40
(1.09)
4.4
(2.00)
4.65
(2.11)
5.17
(2.35)
HIGH
N/A
N/A
2.84
(1.29)
5.5
(2.50)
5.79
(2.63)
7.78
(3.52)
Average steam use per cycle, bhp (kg)
N/A
0.73
(11.3)
1.43
(12.2)
2.32
(15.4)
1.34
(20.9)
1.14
(31.45)
Electrical Heating (Optional)
Total electrical heating capacity, kW
Input Voltage
200V
5.4
5.4
10.8
10.8
21.7
N/A
240V
7.8
7.8
15.6
15.6
31.2
N/A
380V
6.5
6.5
13.0
13.0
19.6
N/A
415V
7.8
7.8
15.5
15.5
23.3
N/A
480V
N/A
N/A
15.6
15.6
31.2
N/A
Electrical heating elements
3
3
3
9
12
N/A
Electrical heat element size, kW
2.6
2.6
5.2
2.6
2.6
N/A
