© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT F8321401 (EN) 18
Basic Installation/Operation
Operating Instructions, Vend
Models Only
1. Turn on main power source (circuit breaker).
2. Turn handle clockwise to open. Refer to Figure
4.
Figure 4
3. Load to capacity whenever possible. DO NOT
OVERLOAD. Refer to Figure 5.
NOTE: Underloading can cause out-of-balance
conditions that can shorten machine life.
Figure 5
4. Close door and turn handle counter clockwise.
Refer to Figure 6.
Figure 6
5. The default wash cycle will display.
6. Select the desired soil setting (select models
only), cycle setting (select models only) and
cycle/temperature. The LED indicator(s) for that
cycle will light.
CHM2243N
U003I
CHM2243N
CHM2244N
To prevent personal injury, avoid contact
with inlet water temperatures higher than
125° Fahrenheit (51° Celsius) and hot
surfaces.
W748
WARNING
