ADC EDU-409 User Manual
Page 5
150-409-115-05, Issue 5
Table of Contents
EDU-409 List 1
January 26, 2000
v
T
ABLE
OF
C
ONTENTS
Overview _______________________________________________ 1
Features .................................................................................... 1
Applications ............................................................................. 2
Product Description ______________________________________ 5
Cover........................................................................................ 5
Front Panel ............................................................................... 6
Installation _____________________________________________ 7
Compatibility ........................................................................... 7
Installing the EDU-409 List 1.................................................. 7
Alarms _________________________________________________ 9
Loopback Operation ____________________________________ 10
Functional Description___________________________________ 11
Doubler Enclosure Capacities with Full Solar Load.............. 12
Alternative Doubler Enclosure Capacities............................. 16
Micro Doubler Capacity Deployment Rules.......................... 18
Ground Faults__________________________________________ 19
Ground Fault Detection.......................................................... 19
Ground Fault Isolation ........................................................... 20
Technical Specifications__________________________________ 21
Product Support ________________________________________ 23
Abbreviations __________________________________________ 24
Glossary _______________________________________________ 25
Certification and Warranty__________________Inside Back Cover
