Illus. No.
Part No.
Qty.
Description
1
151000
2
#6-32 Pal Nut
2
150300
2
#10-16 x 1/2” Hex Washer TEK Screw
3
150008
2
#6-32 x 1-1/4” Phillips Pan Head Machine Screw
4
120716
1
2-Position Terminal Block
5
322812
1
Rear Electric Mounting Plate ONLY
822798
1
Rear Electric Panel Assembly Complete - 230 Volt 1ø
(for gas models Only)
(includes illus. nos. 1 through 14)
830273
1
Rear Electric Panel Assembly Complete - 230 Volt 1ø
(for steam models)
(includes illus. nos. 1 through 14)
830426
1
Rear Electric Panel Assembly Complete - 415 Volt 3ø with 1ø Motor
(for electric models)
(includes illus. nos. 1 through 14 and 16)
6
822799
1
Transformer Assembly - 230 Volt 1ø
830141
1
Transformer Assembly - 415 Volt 3ø
7
136008
2
Fuse Holder ONLY
8
136057
2
1/2-Amp (Slo-Blo) Fuse ONLY
9
150301
4
#8-18 x 7/16” Phillips Pan Head TEK Screw
10
150297
1
#10 x 1/2” Green Hex Washer TEK Screw
11
152004
1
5/16-18 Hex Nut
12
121010
1
L-70 Ground Lug
13
153002
1
5/16” Lock Washer
14
132495
1
3-Pole Contactor
15
121300
3
Open/Closed Bushing
16
131932
1
24V SPST Relay
(for electric heated models Only)
Rear Electric Relay Panel Assembly
