23
Direct Spark Ignition (DSI) Burner Assembly
Illus. No. Part No. Qty. Description
1 817088 1 Direct Spark Ignition (DSI) Burner Box ONLY
816998** 1 Natural Gas Burner Assembly
(includes illus. nos. 1 through 8 and 10 through 31)
817208** 1 Liquid Propane (L.P.) Gas Burner Assembly
(includes illus. nos. 1 through 8 and 10 through 31)
883297 1 D-30 Liquid Propane (L.P.) Conversion Kit
2 809307 1 Ignitor Probe Assembly
3 152013 2 #6-32 Hex Nut
4 150309 5 #10-16 x 1/2” Hex Head TEK Crimptite Screw
5 141104 2 Small Tube Burner
6 150108 2 #8-32 x 1/2” Pan Head Machine Screw
7 128941 1 ADC CE Direct Spark Ignition (DSI) Module (3 tries)
8 151001 2 #8-32 Pal Nut
9 140818* 2 #31 Burner Orifice (natural gas)
140801* 2 #51 Burner Orifice (liquid propane [L.P.] gas)
10 141230 1 1/2” Direct Spark Ignition (DSI) Manifold (2-port)
11 318700 1 Pipe Bracket (bent)
12 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
13 128933 1 1/2” 24 VAC CE Gas Valve (natural gas)
883255 1 1/2” 24 VAC CE Gas Valve (liquid propane [L.P.] gas)
14 141317 1 1/2” Bronze Union Elbow
15 142800 1 1/2” x 18” Pipe
16 318700 2 Pipe Bracket (bent)
17 150309 4 #10-16 x 1/2” Hex Head TEK Crimptite Screw
18 817027 1 Direct Spark Ignition (DSI) Module Mounting Bracket
19 142935 1 1/2” BSPT x 1/2” N.P.T. Transition Coupling
20 150005 2 #6-32 x 1/4” Round Head Machine Screw
21 154004 1 Twin Speed Nut
22 150300 9 #10-16 x 1/2” Hex Washer TEK Screw
23 802799 1 Sail Switch Top and Switch Bracket
24 150303 2 #4 x 3/4” Pan Head “A” Machine Screw
25 122200 1 SPST Sail Switch
26 105500 1 Sail Switch Actuator Rod
27 319202 1 Sail Switch Damper (flat)
28 154002 1 1/8” Push On Fastener
29 130201 1 330º Hi-Limit Manual Reset
30 319704 1 Hi-Limit Mounting Bracket
31 152013 2 #6-32 Hex Nut
* Consult factory for elevations over 2,000 feet.
** Burner orifices are not included and must be ordered separately.
