10
Basket (Tumbler)/Support Assemblies
Illus. No. Part No. Qty. Description
1* 800776 1 Stainless Steel Basket (tumbler) ONLY (without felt collar)
883295 1 Stainless Steel Basket (tumbler)/Support Assemblies Complete
(includes illus. nos. 1 through 10)
2 150313 24 #10-16 x 1/2” TORX + BTN Type 1
3 301420 4 Stainless Steel Basket (tumbler) Rib ONLY
4 150518 1 5/16-18 x 3/8” Socket Button Head Screw
5 100914 4 3/8-16 x 20” Tie Rod
6 153004 4 3/8” Flat Washer
7 817084 1 Basket (tumbler) Support ONLY
8 152005 4 3/8-16 Hex Nut
9 153005 4 3/8” Lock Washer
10 153004 4 3/8” Flat Washer
11 116002 1 Felt Collar ONLY
-- 401010 1 #847 Adhesive for Felt Collar (5.0 oz. tube)
* Felt collar is not included and must be ordered separately.
