5.10.2 The Other 6 Page (OTH 6)

The OTH 6 page displays the following information
(figure 5-125):

The endurance (ENDUR) in hours and minutes. The
endurance is calculated based on the amount of fuel
remaining after subtracting out the reserve (RES)
you entered on the OTH 5 or the OTH 6 page from
the present fuel on board.

The range (RANGE), which is the distance (nautical
miles) that could be flown based on the endurance
calculated above and the present groundspeed.

The fuel efficiency, which is the groundspeed divided
by the present fuel flow.

The desired fuel reserve (RES). Same as displayed
on the OTH 5 page. Changing the reserve on one of
the two pages also changes it on the other page.

5.10.3 The Other 7 Page (OTH 7)
The OTH 7 page displays rate of fuel flow. It has two
formats depending on whether the aircraft is a twin
engine (figure 5-126) or a single engine (figure 5-127).

5.10.4 The Other 8 Page (OTH 8)
The OTH 8 page displays the amount of fuel used. If
interfaced with the ARNAV fuel management computer,
this page displays dashes since the ARNAV system
does not output fuel used. There are two formats for the
page, depending on whether the aircraft is a twin engine
(figure 5-128) or single engine (figure 5-129).

5-41

Figure 5-127

FUEL FLOW |
|
GAL/HR|
|
|
10 |

OTH 7

Figure 5-128

Figure 5-129

FUEL USED |
|
GAL|
|
|
12|

OTH 8

Figure 5-125

FUEL DATA |
|
ENDUR 3:19|
RANGE 597|
NM/GAL 6.2|
RES: 00030|

OTH 6

Figure 5-126

FUEL FLOW |
|
GAL/HR|
ENG 1 15 |
ENG 2 14 |
TOTAL 29 |

OTH 7

FUEL USED |
|
GAL|
ENG 1 17|
ENG 2 16|
TOTAL 33|

OTH 8
