Host RJ-11 IP Gateway User Guide, version 42
AT Commands
S-Registers
S Registers are 1 byte, volatile registers used to store configuration data. They are reset to the
default state whenever modem emulation is enabled, or the ATZ/AT&F command is received.
They can be saved to flash memory with the AT&W command. When the port is opened, the saved
parameters are applied to the port.
Response Codes
%X Any % command is ignored OK(0)
+X Any + command is ignored OK(0)
$Xn Any $ command is ignored including 0
or more digits after the command. OK(0)
Register Contents Default
S0 Automatic Answer(# of RING's) 0 (disabled)
S1 Number of RING's Received 0
S3 Command Line Termination Character CR(13)
S4 Response Formatting Character LF(10)
S5 Command Line Editing Character BS(08)
S12 Guard time on either side of the +++
sequence to break into command mode.
Specified in 50ths of a second. 50
Result Code (ATV1) Numeric (ATV0) Reason
OK 0 Command Successful
CONNECT 1 Connection Established
RING 2 Incoming connection awaiting answer
NO CARRIER 3 Connection Terminated
ERROR 4 Error in AT command string
CONNECT 1200 5 Connected – Serial Port Speed is 1200 baud
NO DIALTONE 6 Not Used
BUSY 7 Not Used
NO ANSWER 8 Not Used
CONNECT 2400 10 Connected – Serial Port Speed is 2400 baud
CONNECT 4800 11 Connected – Serial Port Speed is 4800 baud
CONNECT 9600 12 Connected – Serial Port Speed is 9600 baud
CONNECT 14400 13 Connected – Serial Port Speed is 14400 baud
Command Function Response
