Host RJ-11 IP Gateway User Guide, version 12
Installation
Configuring the IP Address and Interface Port of the Host RJ-
11 IP Gateway
Host RJ-11 IP Gateway Defaults
• Phone port: 8 data bits, no parity, and 1 stop bit (8N1).
• Protocol: American/Bell 212A.
• Maximum baud: 2400.
• DHCP client: disabled.
• IP Address: 192.168.1.3.
Configuring the Host RJ-11 IP Gateway
FIGURE 10. Web Browser : Enter the Location
The web-based interface will open. On the left side of the window are menu options. The central
area of the window is the working area (shown in the close up screen shots for the configuration
settings).
Note: When you have completed configuring the Host RJ-11 IP Gateway, you will
want to reconfigure the IP address on your computer to how it was configured
before you started these steps. Use the directions in this step to reset the configura-
tion.
Note: If you are using the defaults for the Host RJ-11 IP Gateway, you can skip this
section and connect your Host RJ-11 IP Gateway directly to your device and net-
work.
1. Connect the Host RJ-11 IP Gateway to power and connect the Ethernet cable from your computer
to the Host RJ-11 IP Gateway.
2. Type “ http://192.168.1.3:9080 ” (see the example in the screenshot below) in the Address or
Location bar and press the enter key.
Since many cellular carriers block the standard web browser ports (80 and 8080),
the Host RJ-11 IP Gateway uses 9080 by default as the port for the web-based
interface.
http://166.213.236.221:9080 http:192.168.1.3:9080
