Alpine iDA-X001 - Manual (Page 34)

32
-EN
Connections
* 1 NORM EQ
(Black) SWRC G.OUT
(Pink/Black) AUDIO INTERRUPT IN
(Green)
(Green/Black)
(White)
(White/Black)
To iPod
To vehicle Display Interface
JASO Antenna
To vehicle phone
Ignition Key
Speakers
Rear Left
Front Left
CD Changer
(Sold Separately)
Speakers
Amplifier
(Sold Separately)
Rear Left
Front Left
To adaptive steering remote
control interface box
(Brown/Yellow) ADAPTIVE STEERING REMOTE CONTROL IN1
(Brown/Orange) ADAPTIVE STEERING REMOTE CONTROL IN2
To adaptive steering remote
control interface box
To adaptive steering remote
control interface box
ISO Antenna
To amplifier or equalizer
To the instrument cluster
illumination lead
To power antenna
Battery
Front Right
Rear Right
Rear Right
Front Right
Subwoofers
(Blue/White) REMOTE TURN-ON
(Orange) DIMMER
(Red) IGNITION
(Black) GND
(Blue) POWER ANT
BATTERY
(Yellow)
(Grey/Black)
(Grey)
(Violet/Black)
(Violet )
Antenna
Amplifier
(Sold Separately)
Amplifier
(Sold Separately)
To iPod or USB memory
* 1 The system switch is located on the bottom of the unit.
