28
-EN
• Protective circuit is activated due to high temperature.
- The indicafion will disappear when the temperature returns to
normal operating range.
• Malfunction in the CD Changer.
- Consult your Alpine dealer. Press the magazine eject button and
pull out the magazine.
Check the indication. Insert the magazine again.
If the magazine cannot be pulled out, consult your Alpine
dealer.
• Magazine ejection not possible.
- Press the magazine eject button. If the magazine does not eject,
consult your Alpine dealer.
• A disc is left inside the CD Changer.
- Press the eject button to activate the eject function. When the
CD Changer finishes the eject function, insert an empty CD
magazine into the CD Changer to receive the disc left inside
the CD Changer.
• No magazine is loaded into the CD Changer.
- Insert a magazine.
• No indicated disc.
- Choose another disc.
Specifications
FM TUNER SECTION
MW TUNER SECTION
LW TUNER SECTION
USB SECTION
GENERAL
CHASSIS SIZE
NOSEPIECE SIZE
DETACHABLE FRONT PANEL SIZE
• Due to continuous product improvement, specifications and design
are subject to change without notice.
Indication for CD Changer
Tuning Range 87.5-108.0 MHz
Mono Usable Sensitivity 0.7 µV
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531-1,602 kHz
Sensitivity (IEC Standard) 25.1 µV/28 dB
Tuning Range 153-281 kHz
Sensitivity (IEC Standard) 31.6 µV/30 dB
USB requirements USB 1.1/2.0
Max. Power Consumption 500mA
USB Class Mass Storage
File System FAT 12/16/32
MP3 Decoding MPEG-1/2 AUDIO Layer-3
WMA Decoding Windows Media™ Audio
AAC Decoding AAC-LC format “.m4a” file
Number of Channels 2-Channel (Stereo)
Frequency Response* 5-20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
* Frequency response may differ depending on the encoder
software/bit rate.
Power Requirement 14.4 V DC
(11-16 V allowable)
Maximum Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10 k ohms
Weight 1.0 kg (2 lbs. 3 oz)
Width 178 mm (7")
Height 50 mm (2")
Depth 156 mm (6-1/8")
Width 170 mm (6-3/4")
Height 46 mm (1-13/16")
Depth 24 mm (15/16")
Width 107 mm (4-1/4")
Height 46 mm (1-13/16")
Depth 30 mm (1-3/16")
