7
Control Unit
Mounting foot (p.11)
Contacts
Battery compartment
cover (p.10)
External power source socket
Locking pin (p.11)
Flash mode button
(p.18, 27, 33)
* LCD panel
illumination button (p.8)
Custom Function
setting button (p.28)
button
Focusing
lamp button (p.8)
Pilot lamp (p.18)
Test firing button (p.18)
Locking ring (p.11) Flash exposure confirmation lamp (p.18)
High-speed sync
(FP flash) button (p.26)
Shutter curtain
synchronization button
(p.26)
* Plus button
* Minus button
LCD panel (p.8)
* Select/Set
button
button
Channel button
(p.33)
Power switch (p.18)
Flash ratio/
Flash tube/head select
button (p.21, 27, 33)
Asterisked buttons have functions which remain active for 8 sec. after you
press and let go of the button. The illumination lasts for 12 sec.
