26
Basic Operation
1
2
Press the MENU button to display the
On-Screen Menu. Use the Point ▲▼ buttons
to select Sound. Press Point ► button or the
OK button to access the submenu items.
Press the VOLUME+/– buttons on the top control
or on the remote controller to adjust the volume.
The volume dialog box appears on the screen for
a few seconds.
Press the MUTE button on the remote controller
to select On to temporarily turn off the sound. To
turn the sound back on, press the MUTE button
again to select Off or press the VOLUME +/–
buttons. The Mute function is also effective for the
AUDIO OUT jack.
Press the OK button to switch the mute
function On/Off. When the sound is turned
off, On is displayed. Press the VOLUME +/–
buttons again or adjust MIC gain’s volume to
turn the sound back on.
Use the Point ▲▼ buttons to select the
desired submenu item and press OK button to
access the selected item.
Volume
Volume
Mute
Press the Point ► button to turn up the
volume; Press the Point ◄ button to turn down
the volume.
Mute
Menu Operation
Sound Menu
Volume Dialog Box
Remote controller
VOLUME + button
VOLUME - button
MUTE button
Top Control
Approximate level of
the volume.
Press the MUTE button to set the Mute
function On or Off. The dialog box
disappears after 4 seconds.
Direct Operation
VOLUME +/- buttons
Use the Point ▲▼ buttons to switch the MIC
function On/Off, and then press the OK button.
When On is selected, the synthesis volume
(MIC and RCA) is output.
MIC
MIC GAIN
Press the Point ► button to turn up the MIC
mixing gain; Press the Point ◄ button to turn
down the MIC mixing gain.
AUDIO INPUT SELECTION (see pages 16-18)
 Note:
• When Off is selected in MIC function, the MIC GAIN and STANDBY MIC OUT functions are not available.
• Only when the Standby mode is set to Network, STANDBY MIC OUT can be selected.
• If the MIC function is turned on when connecting PC audio to the COMPUTER AUDIO IN 2 (MIC IN), loud
sound may be output suddenly depending on the setting value of MIC GAIN.
STANDBY MIC OUT
When setting the STANDBY MIC OUT function
to On and in Standby mode status, only MIC
input volume can be output.
Sound Adjustment
AUDIO IN
MIC Setup RCA L/R
terminal
COMPUTER
AUDIO IN 1
COMPUTER
AUDIO IN 2
(MIC IN)
MIC Off Video audio PC 1 audio PC 2 audio
MIC On
for Video
Video audio --- MIC
MIC On
for PC 1
--- PC 1 audio MIC
MIC On
for PC 2
--- PC 2 audio MIC
