Canon imagePROGRAF iPF6450 User Manual
Basic guide
Large Format Printer
Basic Guide
Safety Precautions......................................................2
Manuals for this printer ................................................... 6
Handling rolls .................................................................. 9
Handling sheets ............................................................ 18
Ink Tanks...................................................................... 31
Printheads .................................................................... 38
Maintenance Cartridge ................................................. 45
Cleaning the Printer ...................................................... 51
Operations and Display Screen .................................... 61
Printer parts.................................................................. 72
Preparing to Transfer the Printer .................................. 78
Installing the Printer Driver (Windows) ......................... 86
Installing the Printer Driver (Mac OS X) ....................... 88
Convenient Printer Driver Features .............................. 90
Adjustments for Better Print Quality
Adjusting the Printhead ................................................ 97
Adjusting the feed amount ............................................ 99
Problems Regarding Paper ........................................ 102
Printing does not start ................................................. 111
The printer stops during a print job ............................. 112
Problems with the printing quality ............................... 113
Spectrophotometer Trouble Shooting ......................... 124
Cannot print over a network ........................................ 125
Installation problems ................................................... 127
Other problems ........................................................... 129
Messages regarding paper ......................................... 133
Messages regarding ink .............................................. 142
Messages regarding printing or adjustment ................ 144
Messages regarding printheads ................................. 149
Messages regarding the maintenance cartridge ......... 151
Messages regarding the hard disk .............................. 152
Other Messages ......................................................... 154
Error Messages .......................................................... 156
Manuals for this printer
Setup Guide
Basic Guide
User's Guide
Electronic manual
Paper Reference Guide
Electronic manual
ENG
Read this manual before attempting to operate the printer.
Keep this manual in a handy location for future referencing.
ver1.00 2012-06-26
