Configure a storage server group, Change the storage server group name, Configure the low disk space warning level – Canon VB-M600D User Manual
Page 33: Configure a storage server group -5, Change the storage server group name -5, Configure the low disk space warning level -5, X (p. 3-5), P. 3-5)

3
-5
S
to
rage
S
erver
S
et
tin
g
s
3
You can change the name of the Storage Server Group
and configure the free disk space notifications.
Display the [Storage Server Group Settings]
Dialog Box
The [Storage Server Group Settings] dialog box is
displayed.
➀ [Edit]
Change the name of Storage Server Group.
➁ [Recording Settings] tab
Configure the free disk space notifications.
Note
For RM-Lite, the items in the [Recording Settings] tab have the
following limitations.
• The [Mirroring Settings] feature is not available.
• The [Maximum File Size / Duration] setting is not available. The
maximum file size is fixed at 1,024 MB (1 GB) and the
maximum duration is fixed at 24 hours.
• [Reduce recording frame rate when disk is under high load] is
always enabled. You cannot disable it. You can confirm
whether the frame rate has been automatically reduced by
checking the [Live Events Log].
➂ [Events] tab
This cannot be used with RM-Lite.
➃ [OK] and [Cancel]
Close the dialog box.
Change the Storage Server Group Name
Configure the Low Disk Space Warning Level
An event is triggered when the free disk space available
for recording becomes low, relative to the maximum disk
space.
Specify this percentage using the following procedure.
Configure a Storage Server Group
1
Click [Settings] > [Storage Server Group].
➁
➀
➂
➃
1
Click [Edit] to display the [Edit Storage Server Group
Name] dialog box.
2
Change the Storage Server name and click [OK].
1
Click the [Recording Settings] tab.
2
In [Low Disk Space Warning Level], specify the free
disk space level, as a percentage of the maximum disk
space, which will issue a notification.
