3 amplifier jack access card – ADC PWR-AVIS User Manual
Page 31
ADCP-61-814
•
Issue 1
•
April 1999
Page 27
© 1999, ADC Telecommunications, Inc.
4.3 Amplifier Jack Access Card
REAR
EQUIPMENT
CONNECTIONS
75 OHM
JACK ACCESS CARD
REAR INTERFACE UNIT
IN
OUT
0.033
µ
H
INDUCTOR
SPLITTER
MODEM
NETWORK ELEMENTS
10229-A
0, 10 or 20 dB
AMPLIFIER
Figure 34. Typical Interconnect with Gain Application
