ADCP-61-814
•
Issue 1
•
April 1999
Page 11
© 1999, ADC Telecommunications, Inc.
Table 2. PWR AVIS Technical Specifications, continued
PARAMETER SPECIFICATION
Electrical Performance (Amplifier Card)
Gain
0 dB amp card
10 dB amp card
20 dB amp card
0±1 dB, 5 – 100 MHz
10±1 dB, 5 – 100 MHz
20±1 dB, 5 – 50 MHz
Reverse Isolation <-50 dB, 5-50 MHz
<-40 dB, 50-100 MHz
Impedance 75 ohms nominal
Return Loss
Input
Output
<-30 dB, 5-50 MHz
<-20 dB, 50-100 MHz
<-20 dB, 5-50 MHz
<-15 dB, 50-100 MHz
Noise Figure
0 dB
10 dB
20 dB
25 dB Typical
18 dB Typical
17 dB Typical
CSO (typical) 6 channels, T7-T12,
@ 30 dBmV per channel output
0 dB
10 dB
20 dB
−
60 dBc Typical
−
60 dBc Typical
−
50 dBc Typical
CTB (typical) 6 channels, T7-T12,
@ 30 dBmV per channel output
0 dB
10 dB
20 dB
−
70 dBc Typical
−
70 dBc Typical
−
70 dBc Typical
Alarm Contacts Normally open
Environmental
Operating Temperature 32–122 F (0–50 C)
Humidity Range 20–90% non-condensing
