W A R N I N G
* IF INSTRUMENT IS SUBJECTED TO +400°C PLUS
Some instruments use Viton sealant. Above +400°C this material decomposes
producing (amongst others) Hydrofluoric Acid which is extremely corrosive
* DO NOT ALLOW CONTACT WITH SKIN
If it is suspected that an instrument has been subjected to temperatures in
excess of +400°C
* CONTACT OUR SALES OR SERVICE DEPARTMENT TO
ASCERTAIN IF THE INSTRUMENT CONTAINS VITON
W A R N I N G
ELECTRICAL CONNECTIONS
4-20 M A V OLTAGE
I N + I N - G ROUND I N + C OM O UT + G ROUND
C ABLE R BL DRAIN R W Y DRAIN
C ONNECTOR 1 2 E 1 2 3 E
O UTPUT S UPPLY V OLTAGE
4-20mA 9 - 35V d.c.
0.5 - 5.5V d.c. 7.5 - 35V d.c.
1 - 6V d.c. 8 - 35V d.c.
0 - 5V d.c. 7.5 - 35V d.c.
0.1 - 5.1V d.c. 7.5 - 35V d.c.
1 - 5V d.c. 7.5 - 35V d.c.
159 Swanson Road, Boxborough, MA 01719-1304
Tel: 800-257-3872 / 978-263-1400
OP550 Rev A 11/03
