3
3.0 MODEL CWS PERFORMANCE SPECIFICATIONS
Accuracy
±
0.10% FS
Non-Repeatability 0.05% FS
Hysteresis 0.10% FS
Off Center Loading 0.10% FS (at 1 inch)
Overload Protection 150% FS
Thermal Effects
Compensated Range
°
F(
°
C) +14 to +122 (-10 to +50)
Zero Shift %FS/100
°
F (50
°
C) 1.0 (0.9)
Span Shift %FS/100
°
F (50
°
C) 1.0 (0.9)
Long Term Stability 0.5% FS/1 YR
4.0 DIMENSIONAL DIAGRAM
9.25
23.5
9.25
23.5
9.00
22.9
RUBBER FEET
0.75/19 0.87/22 0.97/24.6
STAINLESS STEEL
PAN
IN.
CM
1
16
R
TYP
1
16
R
TYP
IN.
CM
IN/MM
