ROTRONIC Wireless Datalogger System - Manual (Page 9)

E-M-HW4v3-F2-021_10
Rotronic AG
Bassersdorf, Switzerland
Document code Unit
HW4 software v.3: Device Manager and Data
Logging LOG-RC Series Data Loggers Instruction Manual
Document Type
Page 9 of 18
Document title
© 2011; Rotronic AG E-M-HW4v3-F2-021_10
4.2 Devices Tab
The Devices Tab is used to make HW4 detect the wireless data loggers that are currently communicating
with the wireless adapter(s). To do this, click on the “Search” button located at the bottom of the form.
The “OK” button is used to add the selected data loggers to the HW4 Device
Tree as illustrated below.
Any device can be individually selected by clicking on the box located to the
left of the device (a check mark appears). All devices can also be globally
selected or de-selected.
