7
Operation
7.1 Load Resistance Requirements of the Analog Outputs
Depending on the output variant, there are different limit values for the load resistance of the analog outputs.
Output Variant
Load Resistance Specification
0…1 V
≥1 kΩ
0…5 V
≥5 kΩ
0…10 V
≥10 kΩ
0…20 mA
≤500 Ω
4…20 mA
≤500 Ω
